Mitsubishi FX3U Series User Manual

FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
461
B Instruction List
B-3 Applied Instructions ... in Ascending Order of FNC Number
21
Memory Cassette
22
Battery
A
Special Devices (M8000-,D8000-)
B
Instruction List
C
Character-code
D
Discontinued models
Others
181 –
182 COMRD Read Device Comment Data
183 –
184 RND Random Number Generation
185 –
186 DUTY Timing Pulse Generation
187 –
188 CRC Cyclic Redundancy Check
189 HCMOV High Speed Counter Move
Block Data Operation
190, 191 –
192 BK+ Block Data Addition
193 BK- Block Data Subtraction
Block Data Subtraction
194 BKCMP=
Block Data Compare =
195 BKCMP>
Block Data Compare >
196 BKCMP<
Block Data Compare <
197 BKCMP<>
Block Data Compare ≠
198 BKCMP<=
Block Data Compare ≤
199 BKCMP>=
Block Data Compare ≥
Character String Control
200 STR BIN to Character String Conversion
201 VAL Character String to BIN Conversion
202 $+ Link Character Strings
203 LEN Character String Length Detection
204 RIGHT
Extracting Character String Data from the
Right
205 LEFT
Extracting Character String Data from the
Left
206 MIDR Random Selection of Character Strings
207 MIDW
Random Replacement of Character
Strings
208 INSTR Character string search
209 $MOV Character String Transfer
Data Operation 3
210 FDEL Deleting Data from Tables
211 FINS Inserting Data to Tables
212 POP Shift Last Data Read [FILO Control]
Data Operation 3
213 SFR Bit Shift Right with Carry
214 SFL Bit Shift Left with Carry
215 to
219
–
FNC No. Mnemonic Function
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
Data Comparison
220 to
223
–
224 LD=
Load Compare =
225 LD>
Load Compare >
226 LD<
Load Compare <
227 –
228 LD<>
Load Compare ≠
229 LD<=
Load Compare ≤
230 LD>=
Load Compare ≥
231 –
232 AND=
AND Compare =
233 AND>
AND Compare >
234 AND<
AND Compare <
235 –
236 AND<>
AND Compare ≠
237 AND<=
AND Compare ≤
238 AND>=
AND Compare ≥
239 –
Data Comparison
240 OR=
OR Compare =
241 OR>
OR Compare >
242 OR<
OR Compare <
243 –
244 OR<>
OR Compare ≠
245 OR<=
OR Compare ≤
246 OR>=
OR Compare ≥
247 to
249
–
Data Table Operation
250 to
255
–
256 LIMIT Limit Control
257 BAND Dead Band Control
258 ZONE Zone Control
259 SCL Scaling (Coordinate by Point Data)
260 DABIN Decimal ASCII to BIN Conversion
261 BINDA BIN to Decimal ASCII Conversion
262 to
268
–
269 SCL2 Scaling 2 (Coordinate by X/Y Data)
FNC No. Mnemonic Function
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2

Mitsubishi FX3U Series Specifications

General

Model	FX3U Series
Program Memory	64k steps
Execution Speed	0.065 μs/basic instruction
Type	PLC (Programmable Logic Controller)
Power Supply	100-240V AC
I/O Points	Up to 384
Communication	USB
Expansion	Supported via expansion modules
High-Speed Counters	Up to 6 channels
Analog Input/Output	Available via expansion modules
Temperature Range	0 to 55°C
Programming Language	Ladder Logic, Structured Text
Built-in Functions	PID control
Humidity	5 to 95% (non-condensing)
