Mitsubishi FX3U Series User Manual

FX3U Series Programmable Controllers
User’s Manual - Hardwaer Edition
81
6 Examination of System Configuration
6.3 Number of Input/Output Points and Maximum Number of Input/Output Points
1
Introduction
2
Features and Part Names
3
Product Introduction
4
Specifications
5
Version and Peripheral Devices
6
System Configuration
7
Input/Output Nos., Unit Nos.
8
Installation
9
Preparation and Power Supply Wiring
10
Input Wiring
4 Calculate the total number of input/output points.
Total the number of points counted in Steps 1, 2 and 3, and check that it does not exceed 256
points (maximum number of input/output points).
5 When CC-Link or AS-i master is used, count the remote I/O points.
When CC-Link or AS-i master is used, the total number of input/output points of the remote I/O sta-
tions connected on the network and the number of input/output points calculated in the previous
step are 384 or less.
For details, refer to the following subsection.
1. FX
2N-16CCL-M (CC-Link master)
Calculate the number of remote I/O points connected on the network in the following step.
→ When CC-Link master is used, refer to Subsection 6.3.2.
2. FX2N-32ASI-M (AS-i master)
Calculate the number of remote I/O points connected on the network in the following step.
→ When AS-i master is used, refer to Subsection 6.3.3.
≥
Maximum number of
input/output points
256 points
Maximum number of
points controllable on
system
Number of input/output points
+
Total number of input/output points of input/output powered
extension units and input/output extension blocks
(A): Number of input/output points of main unit
(B): Number of input/output points of input/output
powered extension units
(C): Number of input/output points of input/output
extension blocks
(D): Number of remote I/O points of FX
2N -64CL-M or FX 2N -
16LNK-M
(E): Number of special function units/blocks
(A) + (B) (C)+
Number of input/output occupied
points
(E) units × 8 points
Each special function unit/block
used for FROM/TO instructions
occupies eight input or output
points.
(D)+

Mitsubishi FX3U Series Specifications

General

Model	FX3U Series
Program Memory	64k steps
Execution Speed	0.065 μs/basic instruction
Type	PLC (Programmable Logic Controller)
Power Supply	100-240V AC
I/O Points	Up to 384
Communication	USB
Expansion	Supported via expansion modules
High-Speed Counters	Up to 6 channels
Analog Input/Output	Available via expansion modules
Temperature Range	0 to 55°C
Programming Language	Ladder Logic, Structured Text
Built-in Functions	PID control
Humidity	5 to 95% (non-condensing)
