FX3U Series Programmable Controllers
User’s Manual - Hardwaer Edition
89
6 Examination of System Configuration
6.5 Expansion of Main Unit (Calculation of Current Consumption)
1
Introduction
2
Features and
Part Names
3
Product
Introduction
4
Specifications
5
Version and
Peripheral
Devices
6
System
Configuration
7
Input/Output
Nos., Unit Nos.
8
Installation
9
Preparation and
Power Supply
Wiring
10
Input Wiring
4 Determine whether the devices can be connected to the main unit.
Calculate the current to confirm whether the selected extension devices can be connected.
1. Calculate the current consumption of the built-in 24V DC power supply (24V DC service
power supply).
The value obtained by this calculation (when the value is positive) indicates the remaining capacity of 24V DC
service power supply, and the capacity can be used for external loads.
2. Calculate the current consumption of the built-in 5V DC power supply.
If the calculation results for the current consumption for the 24V DC power supply and 5V DC power supply
are negative values, the current consumption exceeds the capacity of the built-in power supply.
Reconfigure the system configuration, adding input/output powered extension units or extension power
supply units.
If the calculation results for the current consumption for the 24V DC power supply and 5V DC power supply
are negative values, add an input/output powered extension unit.
Refer to Section 6.6 "Expansion of FX2N Series I/O Powered Extension Unit (Calculation of Current
Consumption)"
If the calculation results for the current consumption by 5V DC is a negative value, add an extension power
supply unit (FX
3U-1PSU-5V).
Refer to Section 6.8 "Number of Input/Output (Occupied) Points and Current Consumption"
