18.1 BootOS and Standard Monitor OS Required for
installation
Under-mentioned BootOS and Standard monitor OS are necessary to execute utility.
OS name Function overview Storage location
BootOS
Requied for the control of GOT and the communication between PC and GOT.
Installed at factory shipment.
(BootOS can be installed from GT Designer3, GT Designer2 or the CF card.
When installed from GT Designer3, GT Designer2 or the CF card, GOT is
initialized to be the factory shipment status. Standard monitor OS must be pre-
installed in the GOT when installing the BootOS again.)
Built-in flash memory
C: \G1BOOT\
CF card that stores data
with the OS boot drive
set to the A drive
A:\G1BOOT\
Standard
monitor
OS
Required for the GOT operation as the
monitoring function of GOT, installation and
deletion of the OS file or project data, touch
key control or display function of the screen
and guidance.
Required for display and
operation of the user-created
screen and utility screen.
Not installed in GOT at factory
shipment.
Install it from GT Designer3,
GT Designer2 or the memory
card.
At installation, select [Mincho]
or [Gothic] for the 16-dot
standard font.
Built-in flash memory
C:\G1SYS\
CF card that stores data
with the OS boot drive
set to the A drive
A:\G1SYS\
System screen data
System screen management information file
TrueType numerical font
12-dot standard font (Gothic)
16-dot standard font (Mincho)
16-dot standard font (Gothic)
To Next Page
