App - 14
Appendix 1 External Dimensions
(c) External dimensions of RS-232 conversion cable connector
Unit:mm(inch)
Cable model Cable length (m(ft.)) External dimensions
GT01-C30R2-6P 3(10) Fig. 17
GT01-C30R2-9S 3(10) Fig. 18
GT01-C30R2-25P 3(10) Fig. 19
GT10-C30R2-6P 3(10) Fig. 20
50
(1.97)
40
(1.57)
13
(0.51)
3000
(118.11)
35(1.38)
16
(0.63)
13
(0.51)
Fig.17
3000
(118.11)
35(1.38)
50
(1.97)
50
(1.97)
16
(0.63)
16
(0.63)
35
(1.38)
Fig.18
3000
(118.11)
50
(1.97)
16
(0.63)
35(1.38)
53
(2.09)
55(2.17)
16
(0.63)
Fig.19
3000
(118.11)
40
(1.57)
200
(7.87)
Approx. 48
(1.89)
30
(1.18)
Fig.20
