ScreenWorks Software Overview
This chapter has descriptions of windows, menus, dialog boxes, and
toolbar icons of the ScreenWorks
®
System Control Software.
ScreenWorks Software Main Screen
The ScreenWorks Software main screen includes title, menu, and
toolbars across the top, and a status bar at the bottom. The main
working area in the middle can have up to two sections:
• Experiment window, typically occupying the greater proportion
of the main window, for protocol configuration, data viewing and
analysis.
• Instrument Status Panel, by default on the bottom of the main
work area, for instrument information. This panel includes
instrument status and configuration in addition to the Process
Explorer where ‘processes’ used in protocol definition are
located.
Figure 5-1 Diagram of main ScreenWorks Software interface.
Title Bar
Menu Bar
Toolbar
Experiment Window
Instrument Status Panel
Status Bar
