MR TAPCON 230 basic User Manual

7 Functions and settings
138 TAPCON® 230 basic 2117246/02 EN © Maschinenfabrik Reinhausen 2012
7.4.3.2 Assigning function to outputs (GPOs)
You can assign one of the following functions to each of the digital outputs
(GPOs 1 and 2):
Function Description
Off No function selected.
Local/Remote Message: "Local control / remote control".
Undervoltage Message: "Undervoltage blocking".
Overvoltage Message: "Overvoltage blocking".
Undercurrent Message: "Undercurrent blocking".
Overcurrent Message: "Overcurrent blocking".
Desired value 1 Message: "Desired value 1".
Desired value 2 Message: "Desired value 2".
Desired value 3 Message: "Desired value 3".
Trip MPS Message: "Motor protective switch was tripped".
Motor runtime Message: "Motor runtime exceeded".
Motor running Message: "Motor running".
Bandwidth < Message: "Value below bandwidth".
Bandwidth > Message: "Bandwidth exceeded".
GPI 1 Message: "GPI 1 active".
GPI 2 Message: "GPI 2 active".
GPI 3 Message: "GPI 3 active".
GPI 4 Message: "GPI 4 active".
GPI 5 Message: "GPI 5 active".
GPI 6 Message: "GPI 6 active".
Table 42 Functions for digital outputs (GPOs 1 und 2)
The procedure for assigning a function to a digital output is described in the
following sections.
