3-91
Unique Switch 10 – Transmission
Switch
Initial
Setting
Adjust Usage/Comments
7 1 Factory use only
6 0 Factory use only
5 1 Factory use only
4 0 Factory use only
3 1 Including TTI inside the
document
0: No
1: Yes
Setting this bit to “0” transmit the document length
added with the TTI. Setting it to “1” transmit the
length including TTI inside the document. However
in this case, the image at the top of the document
might be overlapped with TTI.
(TTI length: 4.2mm)
2 0 Factory use only
1 1 The number of times PPR is detected during ECM transmission
1 time 2 times 3 times 4 times
0 1 0 0 1 1
0 1 0 1
Unique Switch 11 ∼ 15 – Factory use only
Unique Switch 16 – Transmission
Switch
Initial
Setting
Adjust Usage/Comments
7 1 Available *, # and space
upon F–code box registration
0: No
1: Yes
Determines if the * (asterisk), # (sharp) and space
are available upon F–code box registration.
6 1
Available *, # and space
upon F–code communicating
0: No
1: Yes
Determines if the * (asterisk), # (sharp) and space
are available upon F–code communicating.
5 0 Ignore space in F–code ID
0: Yes
1: No
Determines if checking the space stored in the
F–code ID.
4 1 F–code sub–frame off
0: Send
1: Not send
Do not send the sub–address and password of F–
code box when a point of sending DCS signal after
EOM signal.
3 0 Send F–code box’s TTI
0: No
1: Yes
Transmit the sub–address and box name of F–code
box with F–code polling document.
2 0 Factory use only
1 0 Retrieve document
0: No
1: Yes
Retrieve the document received in F–code
SecureMail box by polling transmission.
0 1 Ignore F–code bit
0: No
1: Yes
Neglect SEP bit of DTC signal or SUB bit of DCS
signal at F–code polled transmission.
Note: The “F–code communication” is possible the SecureMail and Polling operation using the F–code
(SUB/SEP/PWD/SID). However, it is not based on T.33 recommendation.
