EFA-200/-300 7 Measurement data memory
7-11
Storing measured values
✓ The Matrix measurement screen is active.
✓ The intended measurement position corresponds to the displayed target
coordinates. If necessary, alter the target coordinates.
Note: If the measurement is being made in MAX display mode, you must
switch to “LIVE” and then back to “MAX” before storing the value.
This resets any stored MAX value.
⇒ Press the SAVE key.
The indicated measured value, the indicated target coordinates and a
timestamp will be stored in the data pool.
The following appears in the display as confirmation:
• The new target coordinates.
• The number of measured values already stored in the data pool
increments by one.
Note: When the target coordinates are calculated, the coordinate that is
shown farthest to the right in the ranking will be incremented first.
No. Function
1 Field quantity, here B-field
2 Digital display of measured value
3 Units of measurement
4 Analog display of measured value
5 Target coordinates that will be saved with the next measured value:
• The listing depends on the selected ranking
• The coordinate shown farthest to the right is calculated first, i.e. the Y
coordinate in this case.
6 Display field F4: Switch to MEM MATRIX menu.
7 Display field F3: Indication of selected display mode.
8 Display field F2: Switches the target coordinates to limit “A”.
9 Display field F1: Deletes the last measured value saved in the data pool.
10 Number of measured values saved in the data pool.
Table 7-4 Matrix measurement screen elements
