Click the desired tags in the tag filter to select them and limit the search to the files
marked with them. Click the selected tags again to deselect them and broaden the
search.
Tags for Projects, Groups, Sounds, and Samples: 3 Type Levels
For Projects, Groups, Sounds, and Samples, tags are structured into three hierarchical levels
globally called Types. You can select them via the TYPES filter:
â–ª At first the TYPES filter displays the available top-level tags only.
â–ª As soon as you select a tag at the top level, the second level appears underneath with sub-
tags of the selected tag.
â–ª The hierarchical structure means that the sets of sub-tags are specific to each tag of the
level above.
Example: Imagine that you are looking for a shaker Sample from the MASCHINE factory library:
â–ª You have already selected the Maschine product in the Product selector, and the Maschine
2.0 Library bank of this product (for more information on this, see section ↑3.2.3, Select-
ing a Product Category, a Product, a Bank, and a Sub-Bank). For now the TYPES filter
shows only top-level tags:
â–ª In order to find a shaker, you first select the Drums Type from the TYPES filter.
Upon your selection the second level of tags appears underneath:
In this second level, you select the Shaker Sub-Type.
Now the third level appears with Sub-Types like Acoustic, Analog, etc.
Browser
Searching and Loading Files from the Library
MASCHINE STUDIO - Manual - 142
