Main Page
The Filter in the Control area: Main page.
Parameter Description
TYPE Section
Mode Here you can select between four different filter modes: LP (low-
pass), BP (band-pass), HP (high-pass), and Notch. Depending on
the mode selected, the following parameters vary as indicated.
FREQ Section
Cutoff Controls the cutoff frequency of the filter.
Resonance Controls the amount of resonance, i.e. the amount of amplification
near the cutoff frequency. It is not available with filter mode Notch.
MOD Section
Amount This defines how much the Filter gets modulated by the modulation
source.
Source Here you can select between three different modulation sources:
LFO, LFO Sync, and Envelope. Depending on your choice for the
modulation source, the following parameters appear to the right:
Source: LFO
Speed Defines the speed of the modulation in hertz ranging from 0.03 Hz
up to 16 Hz.
LFO Shape Defines how the LFO evolves over time.
Source: LFO Sync
Effect Reference
Filtering Effects
MASCHINE STUDIO - Manual - 679
