Document Revision 4C Electra Elite IPK II
2 - 530 IP Extenders/Mobile ConneX
Related Features
Electra Elite IPK Terminals
Programming
Extended Extensions
10-03-01 ETU Setup
Terminal Type (B1) for ESI
15-07-01 Programmable Function Keys
Assign function keys on multiline telephones of telephone that is extended.
Mobile ConneX
10-03-01 ETU Setup
Terminal Type (B1) for ESI
15-07-01 Programmable Function Keys
Assign VE/SE keys (
03), CAP keys (08), and DSS/BLF keys (01 + Extension) on Mobile
ConneX ports. Assign function keys on multiline telephones of telephone that is extended.
15-02-21 Multiline Telephone Basic Data Setup – Virtual Extension Access Mode (when idle Virtual
Extension key is pressed)
Determine whether an extension Virtual Extension key should be used as a DSS key to the
extension and for receiving calls (0), answering incoming calls and ability to place outgoing ICM
or CO calls (1), or just receiving incoming calls (2). If the key is to be used for outgoing calls, the
extension number of the key must be a real extension or virtual extension number. When the
extension number of the key is a real extension number, and the key is pressed, the real
extension cannot be used. Must be set to 1.
15-09-01 Virtual Extension Ring Assignment
Individually program an extension Virtual Extension key(s) to either ring (1) or not ring (0).
15-18-01 Virtual Extension Key Enhanced Options – Virtual Extension Key Operation Mode
Assign if a call to a Virtual Extension holds (1) on the Virtual Extension or release (0) to the
telephone that answered the Virtual Extension. Must be set to 1.
Operation
Please refer to the IP Gateway Branch Manual(s) for more information.
