NEC Electra Elite IPK II System User Manual

Electra Elite IPK II Document Revision 4C
Multimedia Conference Bridge 2 - 723
Gateway: 0.0.0.0
The PC and CNF ETU must be connected using either a straight Ethernet cable, crossover
cable, or a small HUB. The CNF(16)-U20 ETU uses Medium Dependent Interface Crossover
(MDIX) sensing protocol that allows the ETU to automatically sense the type (straight or
crossover) of Ethernet cable used. To ensure communication between the PC and the ETU,
they must be attached to the same network.
Related Features
None
Programming
 11-02-01 Extension Numbering
Set the extension number for each multimedia conference port.
 11-07 Department Group Pilot Number
Assign a pilot number to the Multimedia Conference bridge department group.
 16-01 Department Group Basic Data Setup
Assign basic function mode for each department group.
 16-02 Department Group Assignment for Extensions
Assign Extension to Department Groups.
 15-03-03 Single Line Telephone Basic Data Setup – Terminal Type
Allow a single line port to receive DTMF tones after the initial call setup, for voice mail always
enter 1.
Operation
To join a conference using intercom:
1. Dial the Conference pilot number.
2. Dial conference password, and press
#.
3. Record name at prompt, and press
#.
4. Enter the conference.
