VLAN IDs range from 1 to 4093. Use a hyphen (-) to specify a range or a comma (,) to
separate VLAN IDs in a list. Spaces and zeros are not permitted. You can specify port
tagging for the VLAN only if the port that you want to add as a tagged port is also member
of the VLAN. To reset the VLAN tag configuration to the defaults, use the None keyword.
12. From the Acceptable Frame menu, specify one if the following types of frames that can be
received on the port:
• Admit All. Untagged frames or priority-tagged frames that are received on the port
are accepted and assigned the value of the port VLAN ID for the port.
This is the
default selection.
• VLAN Only. Untagged frames or priority-tagged frames that are received on the port
are discarded.
• Admit Untagged Only. Untagged frames that are received on the port are accepted.
With the Admit All and VLAN Only selections, VLAN-tagged frames are forwarded in
accordance to the 802.1Q VLAN specification.
13. From the Ingress Filtering menu, select one of the following options:
• Enable.
The frame is discarded if the port is not a member of the VLAN with which
this frame is associated. In a tagged frame, the VLAN is identified by the VLAN ID in
the tag. In an untagged frame, the VLAN is the port VLAN ID specified for the port that
received this frame.
• Disable.
All frames are forwarded in accordance with the 802.1Q VLAN bridge
specification. The default is Disable.
14. In the Port Priority field, specify the default 802.1p priority assigned to untagged packets
arriving at the port.
You can enter a number from 0 to 7.
15. Click the Apply button.
Your settings are saved.
The following table describes the nonconfigurable fields.
Table 31. Nonconfigurable fields on the PVID Configuration page
Field Description
Current Ingress Filtering Indicates whether ingress filtering is enabled for the interface.
Untagged VLANs The number of untagged VLANs for the interface.
Tagged VLANs The number of tagged VLANs for the interface.
Forbidden VLANs The number of forbidden VLANs for the interface.
Dynamic VLANs The number of dynamically added VLANs for the interface.
