8-Port Gigabit (PoE+) Ethernet Smart Managed Pro Switch with (2 SFP or 2 Copper Ports and)
Cloud Management
Manage Device Security User Manual306
4. Enter one of the following passwords:
• After registration, enter the local device password.
By default, the local device password is password.
• If you previously managed the switch through the Insight app or Cloud portal, enter
the Insight network password for the last Insight network location.
For information about the credentials, see
Credentials for the local browser interface on
page 32.
5. Click the Login button.
The System Information page displays.
6. Select Security > Management Security > RADIUS >
Accounting Server Configuration.
7. In the Accounting Server Address field, specify the IP address of the RADIUS accounting
server to add.
8. In the Port field, specify the UDP port number that the server uses to verify the RADIUS
accounting server authentication.
The default UDP port number is 1813.
9. From the Secret Configured menu, select Ye
s to add a RADIUS secret in the next field.
You must select Ye
s before you can configure the RADIUS secret. After you add the
RADIUS accounting server, this field indicates whether the shared secret for this server
was configured.
10. In the Secret field, type the shared secret to use with the specified accounting server
.
11. From the Accounting Mode menu, select Enable to enable the RADIUS accounting mode.
12. Click the Apply button.
Your settings are saved.
13. T
o reset the accounting server and RADIUS statistics to their default values, click the Clear
Counters button.
