8-Port Gigabit (PoE+) Ethernet Smart Managed Pro Switch with (2 SFP or 2 Copper Ports and)
Cloud Management
Get Started User Manual41
4. Enter one of the following passwords:
• After registration, enter the local device password.
By default, the local device password is password.
• If you previously managed the switch through the Insight app or Cloud portal, enter
the Insight network password for the last Insight network location.
For information about the credentials, see
Credentials for the local browser interface on
page 32.
5. Click the Login button.
The System Information page displays.
6. Select System > Device V
iew.
The Device View page displays.
The following figure shows the Device View page for model GS110TPv3.
The Device View page depends on the model:
• GS108Tv3. For model GS108Tv3, each port provides a left LED and a right LED that,
combined, indicate the link and speed, as described in the following table.
Table 4. Device view port LEDs for model GS108Tv3
Left port LED Right port LED Description
Solid green Solid green A valid 1 Gbps port link is established.
Solid green Black A valid 100 Mbps port link is established.
Black Solid green A valid 10 Mbps port link is established.
Black Black No port link is established.
