ZZ set system configuration
IMM PGM MIP
USAGE ♦ ♦
SYNTAX ZZnn or ZZ?
PARAMETERS
Description nn [ int ] - system configuration
Range nn - 0 to 0FFFFH (hexadecimal with leading zero(0) )
or ? to read current setting
Units nn - none
Defaults nn missing: error 38, COMMAND PARAMETER MISSING
out of range: error xx2, PARAMETER OUT OF RANGE
DESCRIPTION This command is used to configure system fault checking, event handling and
general setup for all axes
.
Note:
If bit-0 or both bits-1 and -2 are set to zero(0) then no action will be taken by the
controller.
Note:
The controller always interprets the nn value as a hexadecimal number, even
when the letter "H" is not appended to the desired value. Since nn is a
hexadecimal number, it is possible that the most significant character (left most
character) is an alphabet (A—F) depending on the choice of values for various
bits. In order for the controller to distinguish between an ASCII command and
its value, it is recommended that the users always add a leading zero (0) to the nn
value. See table below for clarification:
Example:
Command Issued Controller Interpretation
1ZZ123H nn = 123H = (0001 0010 0011)Binary
1ZZ123 nn = 123H = (0001 0010 0011)Binary
1ZZ0F25H nn = F25H = (1111 0010 0101) Binary
1ZZF25H Invalid command
Section 3 – Remote Mode 3-173
