Pin # Description

Center Pin Input Emergency Stop must always be

connected to the shell (GND) during normal

controller operation. An open circuit is

equivalent to pressing STOP ALL on the

front panel.

Connector Shield Provides GND for switch

Connector (BNC) with

Dust Cap

Figure C.3: Motor Interlock Connector (BNC) with dust cap
