Nordson ProBlue Flex - Removing the Level Sensor, Melt RTD, or Melt Thermostat

Troubleshooting
6-21
Part 1128350_02
E 2020 Nordson Corporation
Removing the Level Sensor, Melt RTD, or Melt Thermostat
Remove Melter Panels
1. De-energize the melter. Refer to Safe ty (Section 1).
2. Disconnect the melter air supply and remove the air filter.
3. Remove the front panel of the melter by loosening the four latches. See
Figure 6-4.
NOTE: For MOD systems, remove the right and rear panels.
4. Remove the pump cover by unfastening the two screws.
1
2
3
Figure 6-4 Melter panels
1. Front panel 2. Rear panel 3. Right panel
