Connect a Compressed Air Supply
CAUTION! Do not force the air pressure adjustment screw beyond its normal
range of adjustment. Forcing the adjustment screw beyond it s normal range
of adjustment will damage the pneumatic assembly.
1. Use a 5 mm hex wrench to turn the air pressure adjustment screw
counterclockwise until it stops (Off).
1
2
Figure 3-13 Pressure regulator (gauge) and adjustment screw
1. Air pressure gauge 2. Air pres sure adjustment
screw
