Hose/Applicator Expansion Base
G-16
Part 1128350_02
E 2020 Nordson Corporation
I/O Declarations for the 4 Channel Temperature Control
Expansion Board
Connector Terminals Type Rating Use
X5, X2 1to5 Nordnet
24VDC @
2000 mA,
3.3V serial
communication
X5 is used to supply 24VDC and serial communication to
the 4 channel temperature control board
X2 is used to supply 24VDC and serial communication to
the expansion 4 channel temperature control board.
X8 1
Chassis
Ground
Chassis
Ground
Used to supply chassis ground to the 4 channel
temperature control board.
X3, X9 1, 2
Heater
Power
240VAC @
2000W
Used to supply heater power to the 4 channel temperature
control board and to the expansion 4 ch annel temperature
control board.
X6, X1
1, 2, 3, 7,
8, 9
RTD Sensor 5V logic
The RTD sensor inputs provide the heater control
feedback from hose and applicator.
5, 6, 11, 12
Heater
Output
240VAC @
1000W per
zone, 1200W
perpairand
2000W for
base
240VAC provided to hose and applicator heaters.
