Nordson ProBlue Flex - Melter Sub-Base Dimensions

Technical Data
7-13
Part 1128350_02
E 2020 Nordson Corporation
Melter Sub-base Dimensions
37 mm
249 mm
(9.80 in.)
249 mm
(9.80 in.)
55 mm
(2.16 in.)
55 mm
(2.16 in.)
381 mm
(15 in.)
(1.44 in.)
87 mm
(3.44 in.)
35 mm
(1.38 in. [Incoming Power])
8X
9mm
(0.35 in.)
68 mm
(2.69
94 mm
(3.69 in.)
60 mm
(2.36 in.)
in. [with ATS])
Figure 7-4 4 kg melter chassis dimensions
37 mm
249 mm
(9.80 in.)
249 mm
(9.80 in.)
55 mm
(2.16 in.)
55 mm
(2.16 in.)
436 mm
(17.17 in.)
(1.44 in.)
87 mm
(3.44 in.)
35 mm
(1.38 in. [Incoming Power])
8X
9mm
(0.35 in.)
68 mm
(2.69
92 mm
(3.62 in.)
62 mm
(2.44 in.)
in. [with ATS])
Figure 7-5 7 and 10 kg melter chassis dimensions
