Nordson ProBlue Flex - Single Acting High Output Pump Service Kit; Low Viscosity Pump Replacement Service Kit

Parts
8-68
Part 1128350_02
E 2020 Nordson Corporation
Single Acting High Output Pump Service Kit
Kit Part Part Description Quantity
1129107 — KIT,SERVICE,PUMP,H/O,S/A —
------ S O RING,VITON, 3.250X3.375X.063 2
------ S NUT,HEX,LOCK,TORQUE,M6X1, DIN 980V,V3 1
------ S CUP,PISTON,PUMP,HIGH OUTPUT 2
------ S RETAINING RING,INT,125,PUSHON 1
------ S UCUP,.500 ID,1.000 OD, .250,VITON 1
------ S O RING,VITON, 1.500X1.625X.063,-029 1
------ S SEAL,PUMP,HI VOL,S/A 1
------ S O RING,VITON,BLK,1.812X2.000 1
------ S O RING,VITON,1.609x1.887x139,-223 1
------ S O RING,VITON,BLK,1.562X1.750 1
------ S LUBRICANT,O-RING,NSF-H1,10 ML TUBE 1
------ S LABEL,BLANK,3.50"X1.375" 1
------ S BAG,POLY,KITS,ROLLS,5X7 3
------ S BAG,POLY,KITS,ROLLS,3 1/2X5 1/2 8
------ S CARTON,MISCPARTS(6"X4"X2") 1
Low Viscosity Pump Replacement Service Kit
SeeFigure8-37.
Kit Part Item Part Description Quantity
1129109 — KIT,SERVICE,PUMP REPLACEMENT,L/V, D/A —
1 ------ S PUMP,LOW VISCOSITY,D/A 1
2 ------ S ELBOW, MALE,6 MM TUBE X G 1/8 1
3 ------ S LUBRICANT,O-RING,NSF-H1,10 ML TUBE 1
5 ------ S INSERT SET,PUMP,STD D/A 1
6 ------ S CAP/PLUG,TAPERED, .240 O.D. 2
7 ------ S BOX,MPL PUMP,22 1/8" X 6 X 11 1
8 ------ S LABEL,BLANK,3.50"X1.375" 4
10 ------ S BAG,POLY,KITS,ROLLS,3 1/2X5 1/2 2
11 ------ S CAP/PLUG,TAPERED, .302 O.D. 1
12 ------
S LUBRICANT,HIGH-TEMP,NSF-H1,1 OZ.
BOTTLE
1
13 ------ S TAG,CAUTION,OIL AIR LINE,SP PUMP LUB 1
14 ------ S BAG,POLY,KITS,ROLLS,6X10 1
