Nordson ProBlue Flex User Manual

SP Pump Diagnostics and Repair
B-22
Part 1128350_02
E 2020 Nordson Corporation
High Output Double Acting Pump Assembly Parts List
SeeFigureB-6.
Item
Part
Description Quantity
------ ------ PUMP,HIGH OUTPUT DOUBLE ACTING,PB FLEX
1 1127179 SCR,HEX,CAP,M6X110,ZN,CLASS 8.8 4
2 982237 SCR,HEX,CAP,M6X35,ZN 1
3 983410 WASHER,FLT,M,NARROW,M6,STL,ZN 5
4 1044068 CUP,PISTON,PUMP,HIGH OUTPUT 2
5 1044070 WASHER,SEAL,PISTON,PUMP,HIGH OUTPUT 1
6 1044069 WASHER,CUP,PISTON,PUMP,HIGH OUTPUT 2
7 288122 SEAL,PUMP,HI VOL,MPL 1
8 1126626 CYLINDER,AIR,PUMP,HO D/A 1
9 1044791 FORK ASSEMBLY,MAGNETIC,PUMP,H.O. 1
10 1044790 CAGE,BALL,SIPHON,HIGH OUTPUT 1
11 900023 BALL,440SSTL, .750, 50 1
12 1128546 PISTON ASSEMBLY,HYD,HO, D/A,PB FLEX 1
13 940420 O RING,VITON, 3.250X3.375X.063 2
14 941332 O RING,VITON,BLK,1.812X2.000 1
15 1127239 ORING,VITON,1.609x1.887x139,-223 1
16 941290 O RING,VITON,BLK,1.562X1.750 1
17 940293 O RING,VITON, 1.500X1.625X.063,-029 1
18 1044194 UCUP,.500 ID,1.000 OD, .250,VITON 1
19 1047615 RETAINING RING,INT,125,PUSHON 1
20 1064157 NUT,HEX,LOCK,TORQUE,M6X1, DIN 980V,V3 1
21 1126624 BODY,PUMP,HO D/A 1
22 240534 SEAT,SIPHON BALL 1
23 1126627 RETAINER,PUMP BODY,HO D/A 1
24 1126628 NUT,LOCK,BRG,N-07,STL,ZN 1
25 1126625 FRAME,PUMP,HO,MACHINED 1
26 1044053 HEAD,CYLINDER PUMP,HIGH OUTPUT 1
27 1128330 ACTUATOR ASSEMBLY,PUMP 1
28 982298 SCR,HEX,CAP,M5X50,BL 2
29 983408 WASHER,FLT,M,NARROW,M5,STL,Z N 2
30 940111 O RING,VITON,.301ID X .070W,BR, 10411 SB 2
31 1108372 LUBRICANT,O-RING,NSF-H1,FOOD GRADE,4L 1
32 1108371 LUBRICANT,NEVER-SEEZ,NSF-H1,FOOD GRADE 1
