Nordson ProBlue Flex User Manual

Technical Data
7-9
Part 1128350_02
E 2020 Nordson Corporation
Fill System Specifications
Item Data
Adhesive forms
Maximum size
Pellets, pastilles, mini-slats
S Pastilles: 12 mm (0.472 in.) diameter
S Mini-slats: 12 mm X 12 mm (0.472 in. X 0.472 in.) in length
Adhesive transfer maximum rate 275 kg (600 lb)/hour (dependent on adhesive type)
Transfer hose length 4m(13ft),9m(29.5ft),or18m(59ft)
Total air consumption By transfer rate:
S 17 SCFM at 3.4 bar (50 psi) to transfer 105 kg/hr (232 lb/hr) with
a4mhoseata4mrise
S 22 SCFM at 4.1 bar (60 psi) to transfer 113 kg/hr (248 lb/hr) with
a9mhoseata4mrise
S 30SCFMat6.2bar(90psi)totransfer91kg/hr(200lb/hr)withan
18 m hose at a 4 m rise
Average: 1.3 SCFM for a complete system [melter, 4 m transfer hose,
4.1bar(60psi)]operatingat11kg/hr(25lbs/hr)adhesiveoutput
Conditioning Dry, non-lubricated
Operating air:
Dynamic Minimum Pressure 2.75 bar (0.275 MPa or 40 psi)
Maximum Pressure 5.5 bar (0.55 MPa or 80 psi)
Static Maximum Pressure 6.9 bar (0.69 MPa or 100 psi)
Air line tubing size (between solenoid
valve and suction lance)
10 mm OD, 8 mm ID
Inlet air connection ¼ in. NPT female
¼ in. BSPP female
G ¼ female
Dimensions (W x D x H):
Single-feed Adhesive Container
Clearance
480 x 554 x 917 mm (19 x 22 x 36 in)
Multi-feed Adhesive Container
Clearance
688 x 667 x 1656 mm (26 x 27 x 65 in)
Adhesive storage bin capacity:
Single-feed bin 40 kg (88 lb) with optional grate
64 kg (141 lb) usable without grate
Multi-feed bin 40 kg (88 lb) usable with grate
64 kg (141 lb) usable without grate
IP rating (sequencer and adhesive
storage bin)
IP54
Adhesive Bin Factory Pressure Setting SingleFeed:65psi(4.48bar)
Multi-Feed: 75 psi (5.17 bar)
Noise Emission 76 dBa
