Nordson ProBlue Flex - Flow Meter Parts

Adhesive Tracking System
D-12
Part 1128350_02
E 2020 Nordson Corporation
Flow Meter Parts
SeeFigureD-3.
Item Part Description Quantity Note
— ------ FLOWMETER, .150 THK GEAR, ATS — A
1 ------ S BODY,FLOWMETER,ATS 1
2 940310 S O RING,VITON, 1.750X1.875X.063 1
3 ------ S PIN, GEAR, FLOWMETER 2
4 ------ S GEAR,.150THICK,FLOWMETER 2
5 ------ S COVER,FLOWMETER,ATS 1
6 ------ S SCR,SKT,M6X25,ZN 6
7 ------ S ADHESIVE,LOCTITE 242,BLUE,REMOVABLE,
50M
B
NOTE A: To replace the complete flow meter assembly, order service kit 1125294.
B: For additional Loctite 242, order Nordson P/N 900200 (0.5 ml tube).
