Nordson ProBlue Flex - Melter Specifications

Technical Data
7-3
Part 1128350_02
E 2020 Nordson Corporation
Melter Specifications
4, 7, 10 Kg Tank Melters
Tank Size
Specifications 4 7 10
Melt Rate
5kg/hr(11lb/hr) 7kg/hr(15.411lb/hr) 11 kg/hr (24 11 lb/hr)
Throughput
Weight of empty melter 49.8 kg (109.8 lbs) 50.9 kg (112.2 lbs) 53.7 kg (118.4 lbs)
Holding capacity 4.5 kg (9.9 lb) 6.7 kg (14.8 lb) 9.7 kg (21.4 lb)
Dimensions - mm (in.):
Overall
570 mm x 517 mm x 367 mm
(22.5 in x 20.5 in x 14.5 in)
634 mm x 517 mm x 367 mm
(25inx20.5inx14.5in)
Mounting
381 mm x 249 mm
(15inx9.8in)
436mmx249mm(17.1inx9.8in)
Service
748 mm x 635 mm x 672 mm
(29.5 in x 25 in x 26.5 in)
812 mm x 635 mm x 672 mm
(32 in x 25 in x 26.5 in)
Optional 3kVA transformer
dimensions for 480V
570 mm x 593 mm x 367 mm
(22.5 in x 23.5 in x 14.5 in)
634 mm x 593 mm x 367 mm
(25inx23.5inx14.5in)
7and14KgMODMelters
Tank Size
Specifications 7 14
Melt Rate - kg/hr (lb/hr)
7kg(15.4lb/hr) 14 kg (30.8 lb/hr)
Throughput - kg/hr (lb/hr)
Weight of empty melter 50 kg (110.3 lbs)
Weight of melter with full tank 52 kg (114.64 lbs)
Holding capacity 1kg(2.2lb)
Dimensions - mm (in.):
Overall 570 mm x 517 mm x 367 mm (22.5 in x 20.5 in x 14.5 in)
Mounting 381 x 249 (15 x 9.8)
Service 748 mm x 635 mm x 672 mm (29.5 in x 25 in x 26.5 in)
Optional 3kVA transformer
dimensions for 480V
570 mm x 593 mm x 367 mm (22.5 in x 23.5 in x 14.5 in)
A and B Chassis for 240V and 480V Melters
Chassis Type Melter Tank Type
Size A 4 kg, MOD7, and MOD14
Size B 7kgand10kgtank
