Nordson ProBlue Flex - Chassis

Parts
8-6
Part 1128350_02
E 2020 Nordson Corporation
Chassis
SeeFigure8-3forthebaseplate(subbase)partsandFigure8-4forthe
chassis parts.
Item Part Description Quantity Kit P/N
------ MODULE,CHASSIS,1KG,4KG
------ MODULE,CHASSIS, PBF 7/10 KG
101 ------ S CHASSIS,BASE 1
102
------ S BASE PLATE,ASSEMBLY,SIZE 4KG, 7 MOD, 14 MOD
1
1128265
------ S BASE PLATE,ASSEMBLY,SIZE 7/10 KG 1128266
1 ------ SS BASE PLATE,WELDMENT 1
2 240674 SS TAG,GROUND 1
3 1126601 SS HARNESS,GRND,BASE 1
4 983401 SS WASHER,LK,M,SPT,M5,STL,ZN 1
5 984706 SS NUT,HEX,M5,STL,ZN 1
103 1127014 S BRACKET,ACCESS COVER,EBOX 1
104 1127135 S TBACCY,GROUNDING TREE, 8 POS,45 -.25 1
105 230261 S TERMLUG,GROUND,6-14AWG 1
106 1025295 S TAG,PE/G,INPUT POWER,GROUND 1
107 982780 S SCR,SKT,M5X10,ZN 4
108 1037910 S SCREW, SHCS M3X8 ZINC PLATE 2
109 982006 S SCR,SKT,M8X20,ZN 2
110 ------ S TAG,ID PLATE,BLANK 1
111 ------ S RIVET,POP, 1/8X.125,CARBON STL 2
112 ------ S MODULE,TAG,STAMPING 1
