Nordson ProBlue Flex - 7 Kg Tank Module

Parts
8-12
Part 1128350_02
E 2020 Nordson Corporation
7KgTankModule
See Figures 8-7 and 8-6.
Item Part
Description Quantity Kit P/N
— — MODULE,TANK,7L,200/240V 1128152
— — MODULE,TANK, 7KG, 400/480V 1128149
— — MODULE,TANK,7KG,200/240V, NO PTFE —
— — MODULE,TANK,7KG, 400/480V, NO PTFE —
201 — S TANK ASSEMBLY,7KG 1
1 ------ SS TANK,7KG 1
2 ------ SS PCA,SENSOR,PLATE,STUD 1 1128263
3 1127057 SS GASKET,LEVEL SENSOR 1
4 1040011 SS NUT,HEX W/EXT TOOTH WASHER,M4 4
5 1127668 SS STRAINER,TANK 1
6 1127304 SS GASKET,TANK TOP,7/10KG 2
7 1127299 SS EXTENSION,TANK TOP, 7/10KG 1
8 1128731 SS PAN,TANK,TOP,SIZE B,PB FLEX 1
9 1600563 SS NUT,HEX,FLANGED,SERRATED,M5 4
10 ------ SS THERMOSTAT,OOR,500DEG F,PUSH-ON TERM 1 1028321
11 1018189 SS CLIP,RETAINING,RTD 1
12 1003505 SS SCR,SKT,M4X8,SST 4
13 1031007 SS INSULATOR,BOOT,T-STAT,DOUBLE,SILICONE 1
14 1056021 SS SCREW,SET,PARTIAL THD,M6X20 2
202 1127051 S TUBE,CROSSOVER,TANK 1 NS
203 1127215 S ORING,VITON,.859X1.137X1.39,-212 1 NS
204 940141 S O RING,VITON,.489ID X .070W,BR,10414 1 NS
205 1127251 S STUD,THREADED,M8x60 4 NS
206 1091006 S NUT, HEX, FLANGED, SERRATED, M8 4 NS
207 ------ S INSULATION,TANK,7 KG 1
1128255
NS
208 ------ S INSULATION,TRANSFER JOINT 1 NS
209 1017603 S SPACER,BOTTOM, TANK 4 NS
NS: NotShown.The7kgand10kgtanksaresimilar(seeFigure8-6).
Continued...
