Calculating Melter Power Requirements

A-3

Part 1128350_02

E 2020 Nordson Corporation

Table A-1 Hose/Applicator Wattages

Module

Component

Number

Type/Size Wattage Total Wattage

Hose/Applicator

Module 1

Hose 1

Applicator 1

Hose 2

Applicator 2

Total wattage of hose/applicator module 1 =

Hose/Applicator

Module 2

Hose 3

Applicator 3

Hose 4

Applicator 4

Total wattage of hose/applicator module 2 =

Hose/Applicator

Module 3

Hose 5

Applicator 5

Hose 6

Applicator 6

Total wattage of hose/applicator module 3 =

Table A-2 Maximum Allowable Wattages

Component

Plant Voltage

200 VAC 220 VAC 230 VAC 240 VAC

Any hose or applicator 870 W 957 W 1000 W 1043 W

Any hose/applicator pair 1071 W 1179 W 1233 W 1286 W

Any hose/applicator module 1740 W 1913 W 2000 W 2086 W
