Basic Melter Operation
4-3
Part 1128350_02
E 2020 Nordson Corporation
CAUTION: If the hot melt is in the form of pellets or slats, use a scoop to fill
the tank. Never use your bare hands. Using your bare hands to fill the tank
may result in personal injury.
1. Open the tank lid.
12.70 mm
(.50 in.)
Figure 4-1 Tank fill line
2. Fill the tank with hot melt up to the tank fill line. See Figure 4-1.
3. Close the tank lid when you are finished filling the tank.
