NTI ENVIROMUX Series User Manual

NTI ENTERPRISE ENVIRONMENT MONITORING SYSTEM
123
E-16D SPECIFICATIONS
Front Panel Interface
LEDs..............................................................Green – Power, Solid for Main power, flashing for Backup power
.............................................................Red – Low Bat (solid for charging battery, blinking for fault)
.............................................................Green – Check Log
…………………………………………….Green – AUX (not used)
.............................................................Red – Internal Sensor Alert
.............................................................Red – External Sensor Alert
USB………………………………………………USB Type A Female X2, USB 2.0 Full Speed compatible
Buttons…………………………………………..Alarm Test/Silence- momentary switch
………………………………………….. Restore Defaults- momentary switch
………………………………………….. System Reset- momentary switch
RJ45 Sensor Inputs
Connector ......................................................RJ45 connector
Voltage Supply...............................................5VDC and 12VDC
Signal Type....................................................RS485 for RS485 sensors; 2-wire for contact sensors
Max. Cable Length.........................................1000 FT
ESD Protection ..............................................IEC 61000-4-2
Fuse Protection..............................................12V Resetable poly fuse – 500mA hold, 1A trip; 15VDC max. One fuse shared by
ports 1-8, another fuse shared by ports 9-16. .
.......................................................................5V Resetable poly fuse - 750mA hold, 1.5A trip; 16VDC max. One fuse shared by
all 16 ports
Digital Inputs
Connector ......................................................Detachable terminal block-plug-in, 8 x 4 contacts
Wire Range....................................................16-26 AWG
Max. Input Voltage.........................................25VDC
Max. Contact Resistance...............................1K Ohm
Auxiliary Voltage Supply ................................12VDC+/-10%
Max. Current Supply......................................50 mA (terminals 1-7) 350mA (terminal 8 only
)
ESD Protection ..............................................IEC 61000-4-2
Fuse Protection..............................................Resetable poly fuse – 200mA hold, 400mA trip; 16VDC max. One fuse shared by 2
ports
Output Relays
Connector ......................................................Detachable terminal block-plug-in, 4 x 3 contacts
Wire Range....................................................16-26 AWG
Output Type...................................................Dry contact, relay isolated
Output Rating.................................................1A / 30 VDC, 0.5A / 100VAC
Contact Resistance........................................20 milliohm
ESD Protection ..............................................No, Relay Isolated.
Fuse Protection..............................................Non-resetable, 2A Hold, 4A trip, 125V
Beacon Port & Siren Port
Connector ......................................................Detachable terminal block-plug-in, 1x2 contacts
Wire Range....................................................16-26 AWG
Voltage Output...............................................12VDC+/-10%
Current Output...............................................180mA
ESD Protection ..............................................IEC 61000-4-2,
Fuse Protection..............................................Resetable poly fuse – 200mA hold, 400mA trip; 16VDC max.
Warning: The digital output relay
contacts are not to be connected
directly to AC mains wiring.

NTI ENVIROMUX Series Specifications

General

Product Type	Environmental Monitoring System
Temperature Range	-40°C to 85°C
Power Supply	12V DC or 24V AC
Network Interface	Ethernet 10/100 Mbps
Alarm Notifications	Email, SNMP
Sensor Types Supported	Temperature, Humidity, Water, Airflow
Power	12V DC or 24V AC
Operating Temperature	-40°C to 85°C
Mounting	Wall or Rack Mount
Communication Interfaces	Ethernet
Data Logging	Yes
Compliance	CE, RoHS
