NTI ENTERPRISE ENVIRONMENT MONITORING SYSTEM
76
Figure 86- Configure 3G Data Connection
VLAN Settings Description
Enable 802.1Q VLAN Select between "Disabled" (the default) or "Enabled"
VLAN ID Enter a number between 0-4095 for your VLAN ID
SMTP Settings
SMTP Server Enter a valid SMTP server name (e.g. yourcompany.com)
Port
Enter a valid port # (default port is 25, for SSL most use 465, for STARTTLS most use 587)
Email Format Choose between sending emails in Plain Text format (the default) and HTML format
Use SSL Place a checkmark in the box if the SMTP server supports SSL
Use STARTLS Place a checkmark in the box if the SMTP server supports TLS
Use XOAUTH2 Place a checkmark in the box if the SMTP server supports OAUTH authentication (i.e. Gmail
server)
Use Authentication Place a checkmark in the box if the SMTP server requires authentication to send email
Username Enter a valid username to be used by the ENVIROMUX to send emails
Password Enter a valid password assigned to the ENVIROMUX username
SNMP Settings
Enable SNMP agent Place a checkmark in the box to enable access to the SNMP agent. Choose between v1/v2c,
v3 only (maximum security), or v1/v2c/v3.
Enable SNMP traps Place a checkmark in the box to allow SNMP traps to be sent
Read-write community name Enter applicable name (commonly used- “private”)
Read-only community name Enter applicable name (commonly used- “public”)
Server Settings
Enable Telnet Place a checkmark in the box to enable access to the ENVIROMUX via Telnet
By default Telnet is disabled.
Enable SSH Place a checkmark in the box to enable access to the ENVIROMUX via SSH
Enable HTTP access Place a checkmark in the box to enable access to the ENVIROMUX via standard (non-secure)
HTTP requests. Don't disable until you read the notes below (the first two notes at the
top of the next page).
HTTP Port Port to be used for standard HTTP requests.
HTTPS Port Port to be used for HTTPS requests
Web Timeout Number of minutes after which idle web uses will be logged-out (enter 0 to disable this feature)
Console Timeout Number of minutes after which idle console user will be logged-out (minimum is 1 to enable
the feature or enter 0 to disable this feature). This setting effects Console, Telnet and SSH
connections.
Enable Modbus Place a checkmark in the box to enable access via Modbus software
Modbus Port Enter a valid port number to be used to communicate via Modbus (default is 502)
Enable Network Security Place a checkmark here to disable ICMP responses and limit TLS to use only secure ciphers
