NTI ENTERPRISE ENVIRONMENT MONITORING SYSTEM
30
With a successful log in, a screen similar to the following will appear:
Figure 29- Summary page
The initial page includes the Summary page, and a menu to the left with access to all pages used to manage the functions of the
ENVIROMUX.
Function Description
MONITORING Monitor all the sensor and data input received by the ENVIROMUX (below)
ADMINISTRATION Configure all network and multi-user access settings (page 66)
SMART ALERTS View and configure the Events used for Smart Alerts and the Smart Alerts
themselves (page 102)
LOG View and configure the Event and Data Logs (page 115)
SUPPORT Links for downloading a manual, the MIB file, or firmware upgrades
LOGOUT Log the user out of the ENVIROMUX web interface
Monitoring
Under Monitoring, there are links to view the sensors, IP cameras, IP address data and more being monitored by ENVIROMUX.
Topic Description
Summary Lists all monitored items , including their type, description, value, and status
Alarm Information Lists all sensors that are in alarm state including their type, description, value, and status (page 35)
Sensors Provides a link to view the status of specific Internal and External Sensors (page 36 and 42 )
Digital Inputs Provides a link to view the status of each Digital Input (page 51)
IP Devices Provides a link to view the status of only the IP Devices and a link to add them (page 56 )
IP Sensors Provides a link to view the status of each IP Sensor configured (page 60)
SNMP Sensors Provides a link to view the status of SNMP monitored conditions in network-connected devices
Output Relays Provides a link to view the status of each Output Relay (page 54)
IP Cameras Provides a link to view each IP camera defined- with a link to the configuration page (page 56)
Power Supplies Provides a link to view the status of each power supply- with a link to the configuration page (page 32)
