NTI ENVIROMUX Series User Manual

NTI ENTERPRISE ENVIRONMENT MONITORING SYSTEM
3
MATERIALS
Materials included with the E-16D kit:
 E-16D Large Enterprise Environment Monitoring System
 Power Cord- country specific (2 power cords for model E-16DDP)(excluded in E-16D-48V/-24V)
 1-CB4306 USB2-AB-6-5T 2 meter USB 2.0 male type A-male type-B transparent cable
 CT6182 DB9 Female-to-RJ45 Female adapter
 1- CB7339 5 foot RJ45-to-RJ45 CAT5 SF patch cable
 Rack mount kit
Materials included with the E-5D kit:
 NTI E-5D Medium Enterprise Environment Monitoring System
 1- PS4225 120VAC or 240VAC at 50 or 60Hz-9VDC/3A AC Adapter (excluded in E-5D-48V(DP))
-OR-
1- PS4264 120VAC or 240VAC at 50 or 60Hz-9VDC/5A AC Adapter (E-5D(B)-IND only)
 1- Line cord- country specific (excluded in E-5D-48V(DP))
 1- CB4306 USB2-AB-2M-5T 2 meter USB 2.0 male type A-male type-B transparent cable
 1- CT6182 DB9 Female-to-RJ45 Female adapter
 1- CB7339 5 foot RJ45-to-RJ45 CAT5 SF patch cable
Materials included with the E-2D kit:
 NTI E-2D Small Enterprise Environment Monitoring System
 1- PS4225 120VAC or 240VAC at 50 or 60Hz-9VDC/3A AC Adapter (excluded in E-2D-24V)
 1- Line cord- country specific (excluded in E-2D-24V)
 1- CB4306 USB2-AB-2M-5T 2 meter USB 2.0 male type A-male type-B transparent cable
Materials required for connection but not supplied:
 Cables required for connection:
Cat5 for RS485 sensors with RJ45 connectors wired to the TIA/EIA-568B standard (see page 130 for
specifications)
E-2W-xx 2-wire sensor cables for dry contact sensors
 Cable required for Ethernet connection:
Cat5 cable with RJ45 connectors wired straight through (pin 1 to pin 1, pin 2 to pin 2, etc..)
 E-TRMPLG Terminating Plug- one required if multiple E-16D units will be cascaded using the RS485 connection
method (page 96)
See our webpage for the latest sensors available; http://www.networktechinc.com/environment-monitor-16d.html
Contact your nearest NTI distributor or NTI directly for all of your cable needs at 800-RGB-TECH (800-742-8324) in US & Canada
or 330-562-7070 (Worldwide) or at our website at www.networktechinc.com
and we will be happy to be of assistance.

NTI ENVIROMUX Series Specifications

General

Product Type	Environmental Monitoring System
Temperature Range	-40°C to 85°C
Power Supply	12V DC or 24V AC
Network Interface	Ethernet 10/100 Mbps
Alarm Notifications	Email, SNMP
Sensor Types Supported	Temperature, Humidity, Water, Airflow
Power	12V DC or 24V AC
Operating Temperature	-40°C to 85°C
Mounting	Wall or Rack Mount
Communication Interfaces	Ethernet
Data Logging	Yes
Compliance	CE, RoHS
