NTI ENTERPRISE ENVIRONMENT MONITORING SYSTEM

Alarm Summary

To view only those sensors in an alarm state, select the Alarm Summary page under Monitoring. To enable or disable all alerts,

use the "Alert Manage" buttons at the bottom of this page.

Figure 34- Alarm Summary Page

Orange = Non-

critical alert alarm

Red = Critical alert

alarm

Black = Sensor is

in normal status

Table of Contents4
