NTI ENTERPRISE ENVIRONMENT MONITORING SYSTEM
73
In the same screen as the GSM Modem Status is the selection for the SMS message format. Three settings are available for this
format:
Default: With this setting, if your language setting is English, the SMS messages will be sent in Plain
Text. If the language setting is other than English, the SMS messages will be sent in PDU (Protocol
Description Unit) format. This is a format supported by carriers that support extended character sets
other than English.
Plain Text: With this setting, regardless of what the language setting is, SMS messages will be sent in a
plain text format.
PDU: With this setting, regardless of what the language setting is, SMS messages will be sent in PDU
format.
Figure 81- Example of Plain Text SMS Test Message
To test the modem function, click on "Send Test SMS to All Users" to send a test message to everyone that has been setup to
receive SMS messages from the ENVIROMUX.
Enable SMS Relay
If your network includes more than one ENVIROMUX (E-16D, E-5D and/or E-2D), only one GSM modem is required for all the
ENVIROMUX units to send SMS messages. That GSM modem can be connected to any of the ENVIROMUX units. Using the
SMS Relay feature, all ENVIROMUX units can send SMS messages through the single GSM modem.
To use the SMS Relay feature;
- If the GSM modem is connected to the ENVIROMUX you are configuring
, place a checkmark in “Enable Server” block.
- If the GSM modem is connected to another ENVIROMUX unit
, leave “Enable Server” unchecked and instead place a
checkmark in “Use remote unit to send SMS” and enter the IP address of the ENVIROMUX unit that has the GSM
modem connected to it in the block “Remote unit IP Address”.
Be sure to click “Save” to save the configuration.
Figure 82- SMS Relay Configuration
Note: To use the SMS relay feature between two ENVIROMUXs on a network separated by a firewall, be sure to open
ports 6001 and 6002 in the firewall configuration to enable SMS communication between the ENVIROMUXs
These are used if the GSM modem for
SMS alert messages is connected to
another ENVIROMUX on the network.
If your network has only one ENVIROMUX connected to it, the SMS Relay feature will have no effect
3G and 4G
SMS message
capabilities are
supported,
provided the
modem
supports them.
