NTI ENTERPRISE ENVIRONMENT MONITORING SYSTEM

Data Logging

Add to data log This is a check-box that lets the user decide if the data sampled should be recorded in the Data

Log.

Logging Period Enter the time period between logged measurements

Figure 66- SNMP Sensor Configuration page
