NTI ENVIROMUX Series User Manual

NTI ENTERPRISE ENVIRONMENT MONITORING SYSTEM
42
Figure 40- Sensor Configuration Page (4)
External Sensor Configuration
Sensor Settings Description
Description The description of the sensor that will be viewed in the Summary page and in the body of alert
messages
Units This lets the operator choose between Celsius and Fahrenheit as the temperature
measurement unit.
Min. Level Displays the minimum value that this sensor will report
Max. Level Displays the maximum value that this sensor will report
Minimum Non-Critical -
Threshold
The user must define the lowest acceptable value for the sensors. If the sensor measures a
value below this threshold, the sensor will move to non-critical alert status. The assigned value
should be
 within the range defined by Minimum Level and Maximum Level and
 lower than the assigned Maximum Threshold value.
If values out of the range are entered, and error message will be shown.
Maximum Non-Critical
Threshold
The user must define the highest acceptable value for the sensors. If the sensor measures a
value above this threshold, the sensor will move to non-critical alert status. The assigned value
should be
 within the range defined by Minimum Level and Maximum Level and
 higher than the assigned Minimum Threshold value.
If values out of the range are entered, and error message will be shown.
Minimum Critical Threshold The user must define the lowest acceptable value for the sensors. If the sensor measures a
value below this threshold, the sensor will move to alert status. The assigned value should be
 within the range defined by Minimum Level and Maximum Level,
 lower than the assigned Maximum Threshold value, and
 lower than the Minimum Non-Critical Threshold value.
If values out of the range are entered, and error message will be shown.
Maximum Critical Threshold The user must define the highest acceptable value for the sensors. If the sensor measures a
value above this threshold, the sensor will move to alert status. The assigned value should be
 within the range defined by Minimum Level and Maximum Level,
 higher than the assigned Minimum Threshold value, and
 higher than the Maximum Non-Critical Threshold value.
If values out of the range are entered, and error message will be shown.
Enable Disconnection Alert If this sensor is disconnected its status will change to alarm and an alert will be sent
Refresh Rate Determines how often the displayed sensor value is refreshed on the Sensor page. A numeric
value and a measurement unit (minimum 1 seconds, maximum 999 minutes) should be entered.
Enable Graph Apply a checkmark if graphs are desired for this sensor. Up to 150 sensor graphs are
supported. This is checked by default until 150 sensors or more are being monitored.
Group Settings Description
Group Assign the sensor to any or all groups 1 -8 (see also page 44)

NTI ENVIROMUX Series Specifications

General

Product Type	Environmental Monitoring System
Temperature Range	-40°C to 85°C
Power Supply	12V DC or 24V AC
Network Interface	Ethernet 10/100 Mbps
Alarm Notifications	Email, SNMP
Sensor Types Supported	Temperature, Humidity, Water, Airflow
Power	12V DC or 24V AC
Operating Temperature	-40°C to 85°C
Mounting	Wall or Rack Mount
Communication Interfaces	Ethernet
Data Logging	Yes
Compliance	CE, RoHS
