M_CAN_ILE field descriptions
Field Description
0–29
Reserved
This field is reserved.
This read-only field is reserved and always has the value 0.
30
EINT1
Enable Interrupt Line 1
0 M_CAN interrupt line 1 disabled
1 M_CAN interrupt line 1 enabled
31
EINT0
Enable Interrupt Line 0
0 M_CAN interrupt line 0 disabled
1 M_CAN interrupt line 0 enabled
3.3.18 Global Filter Configuration Register (M_CAN_GFC)
Global settings for Message ID filtering. The Global Filter Configuration controls the
filter path for standard and extended messages as described in the Standard Message ID
Filtering and Extended Message ID Filtering.
Address: 0h base + 80h offset = 80h
Bit 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
R
0
W
Reset
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bit
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
0
ANFS ANFE RRFS RRFE
W
Reset
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
M_CAN_GFC field descriptions
Field Description
0–25
Reserved
This field is reserved.
This read-only field is reserved and always has the value 0.
26–27
ANFS
Accept Non-matching Frames Standard
Defines how received messages with 11-bit IDs that do not match any element of the filter list are treated.
NOTE: This field has Protected Write status.
00 Accept in Rx FIFO 0
01 Accept in Rx FIFO 1
10 Reject
11 Reject
Table continues on the next page...
Memory Map and Register Description
MPC5777C Reference Manual Addendum, Rev. 1, 12/2015
56 Freescale Semiconductor, Inc.
