M_CAN_HPMS field descriptions (continued)
Field Description
16
FLST
Filter List
Indicates the filter list of the matching filter element.
0 Standard Filter List
1 Extended Filter List
17–23
FIDX
Filter Index
Index of matching filter element. Range is 0 to SIDFC[LSS] - 1 resp. XIDFC[LSE] - 1.
24–25
MSI
Message Storage Indicator
00 No FIFO selected
01 FIFO message lost
10 Message stored in FIFO 0
11 Message stored in FIFO 1
26–31
BIDX
Buffer Index
Index of Rx FIFO element to which the message was stored. Only valid when MSI[1] = 1.
3.3.23 New Data 1 Register (M_CAN_NDAT1)
Address: 0h base + 98h offset = 98h
Bit 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
ND1
W
Reset
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
M_CAN_NDAT1 field descriptions
Field Description
0–31
ND1
New Data[0:31]
The register holds the New Data flags of Rx Buffers 0 to 31. The flags are set when the respective Rx
Buffer has been updated from a received frame. The flags remain set until the CPU clears them. A flag is
cleared by writing a 1 to the corresponding bit position. Writing a 0 has no effect. A hard reset will clear the
register.
0 Rx Buffer not updated
1 Rx Buffer updated from new message
Memory Map and Register Description
MPC5777C Reference Manual Addendum, Rev. 1, 12/2015
60 Freescale Semiconductor, Inc.
