M_CAN_IE field descriptions (continued)
Field Description
30
RF0WE
Rx FIFO 0 Watermark Reached Interrupt Enable
0 Interrupt disabled
1 Interrupt enabled
31
RF0NE
Rx FIFO 0 New Message Interrupt Enable
0 Interrupt disabled
1 Interrupt enabled
3.3.16 Interrupt Line Select Register (M_CAN_ILS)
The Interrupt Line Select register assigns an interrupt generated by a specific interrupt
flag from the Interrupt Register to one of the two module interrupt lines.
Address: 0h base + 58h offset = 58h
Bit 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
R
STEL FOEL
ACKEL
BEL
CRCEL
WDIL BOL EWL EPL ELOL BEUL BECL DRXL
TOOL
MRAFL
TSWL
W
Reset
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bit
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
TEFLL
TEFFL
TEFWL
TEFNL
TFEL TCFL TCL
HPML
RF1LL
RF1FL
RF1WL
RF1NL
RF0LL
RF0FL
RF0WL
RF0NL
W
Reset
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
M_CAN_ILS field descriptions
Field Description
0
STEL
Stuff Error Interrupt Line
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
1
FOEL
Format Error Interrupt Line
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
2
ACKEL
Acknowledge Error Interrupt Line
Table continues on the next page...
