M_CAN_ILS field descriptions (continued)
Field Description
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
3
BEL
Bit Error Interrupt Line
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
4
CRCEL
CRC Error Interrupt Line
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
5
WDIL
Watchdog Interrupt Line
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
6
BOL
Bus_Off Status Interrupt Line
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
7
EWL
Warning Status Interrupt Line
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
8
EPL
Error Passive Interrupt Line
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
9
ELOL
Error Logging Overflow Interrupt Line
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
10
BEUL
Bit Error Uncorrected Interrupt Line
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
11
BECL
Bit Error Corrected Interrupt Line
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
12
DRXL
Message stored to Dedicated Rx Buffer Interrupt Line
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
13
TOOL
Timeout Occurred Interrupt Line
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
14
MRAFL
Message RAM Access Failure Interrupt Line
Table continues on the next page...
