M_CAN_ILS field descriptions (continued)
Field Description
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
15
TSWL
Timestamp Wraparound Interrupt Line
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
16
TEFLL
Tx Event FIFO Element Lost Interrupt Line
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
17
TEFFL
Tx Event FIFO Full Interrupt Line
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
18
TEFWL
Tx Event FIFO Watermark Reached Interrupt Line
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
19
TEFNL
Tx Event FIFO New Entry Interrupt Line
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
20
TFEL
Tx FIFO Empty Interrupt Line
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
21
TCFL
Transmission Cancellation Finished Interrupt Line
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
22
TCL
Transmission Completed Interrupt Line
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
23
HPML
High Priority Message Interrupt Line
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
24
RF1LL
Rx FIFO 1 Message Lost Interrupt Line
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
25
RF1FL
Rx FIFO 1 Full Interrupt Line
0 Interrupt assigned to M_CAN interrupt line 0
1 Interrupt assigned to M_CAN interrupt line 1
26
RF1WL
Rx FIFO 1 Watermark Reached Interrupt Line
Table continues on the next page...
