M_CAN_TXBCF field descriptions (continued)
Field Description
Each Tx Buffer has its own Cancellation Finished bit. The bits are set when the corresponding TXBRP bit
is cleared after a cancellation was requested via TXBCR. In case the corresponding TXBRP bit was not
set at the point of cancellation, CF is set immediately. The bits are reset when a new transmission is
requested by writing 1 to the corresponding bit of register TXBAR.
0 No transmit buffer cancellation
1 Transmit buffer cancellation finished
3.3.41 Tx Buffer Transmission Interrupt Enable Register
(M_CAN_TXBTIE)
Address: 0h base + E0h offset = E0h
Bit 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
TIE
W
Reset
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
M_CAN_TXBTIE field descriptions
Field Description
0–31
TIE
Transmission Interrupt Enable
Each Tx Buffer has its own Transmission Interrupt Enable bit.
0 Transmission interrupt disabled
1 Transmission interrupt enable
3.3.42 Tx Buffer Cancellation Finished Interrupt Enable Register
(M_CAN_TXBCIE)
Address: 0h base + E4h offset = E4h
Bit 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
CFIE
W
Reset
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
M_CAN_TXBCIE field descriptions
Field Description
0–31
CFIE
Cancellation Finished Interrupt Enable
Each Tx Buffer has its own Cancellation Finished Interrupt Enable bit.
0 Cancellation finished interrupt disabled
1 Cancellation finished interrupt enabled
Chapter 3 Modular CAN (M_CAN)
MPC5777C Reference Manual Addendum, Rev. 1, 12/2015
Freescale Semiconductor, Inc. 75
