M_CAN_GFC field descriptions (continued)
Field Description
28–29
ANFE
Accept Non-matching Frames Extended
Defines how received messages with 29-bit IDs that do not match any element of the filter list are treated.
NOTE: This field has Protected Write status.
00 Accept in Rx FIFO 0
01 Accept in Rx FIFO 1
10 Reject
11 Reject
30
RRFS
Reject Remote Frames Standard
NOTE: This field has Protected Write status.
0 Filter remote frames with 11-bit standard IDs
1 Reject all remote frames with 11-bit standard IDs
31
RRFE
Reject Remote Frames Extended
NOTE: This field has Protected Write status.
0 Filter remote frames with 29-bit extended IDs
1 Reject all remote frames with 29-bit extended IDs
3.3.19 Standard ID Filter Configuration Register (M_CAN_SIDFC)
Settings for 11-bit standard Message ID filtering. The Standard ID Filter Configuration
controls the filter path for the standard messages as described in Standard Message ID
Filtering.
Address: 0h base + 84h offset = 84h
Bit 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
0
LSS FLSSA
0
W
Reset
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
M_CAN_SIDFC field descriptions
Field Description
0–7
Reserved
This field is reserved.
This read-only field is reserved and always has the value 0.
8–15
LSS
List Size Standard
Table continues on the next page...
Chapter 3 Modular CAN (M_CAN)
MPC5777C Reference Manual Addendum, Rev. 1, 12/2015
Freescale Semiconductor, Inc. 57
