M_CAN_RXESC field descriptions (continued)
Field Description
101 32 byte data field
110 48 byte data field
111 64 byte data field
24
Reserved
This field is reserved.
This read-only field is reserved and always has the value 0.
25–27
F1DS
Rx FIFO 1 Data Field Size
NOTE: This field has Protected Write status.
000 8 byte data field
001 12 byte data field
010 16 byte data field
011 20 byte data field
100 24 byte data field
101 32 byte data field
110 48 byte data field
111 64 byte data field
28
Reserved
This field is reserved.
This read-only field is reserved and always has the value 0.
29–31
F0DS
Rx FIFO 0 Data Field Size
NOTE: This field has Protected Write status.
000 8 byte data field
001 12 byte data field
010 16 byte data field
011 20 byte data field
100 24 byte data field
101 32 byte data field
110 48 byte data field
111 64 byte data field
