Oki Data CONFIDENTIAL
45762101TH Rev.1
3-14
3. MAINTENANCE MENUS
3.4.2 Ordinary self-diagnostic mode (level 1)
Menu items of the ordinary self-diagnostic mode are shown below.
Item
Self-diagnostic
menu
Adjustment contents
1 Switch scan test SWITCH SCAN Entry sensor check and switch check
2
Motor clutch test MOTOR&CLTCH
TEST
Motor and clutch operation test
3
Test print
execution
TEST PRINT PU built-in test pattern print
4
Consumable item
counter display
CONSUMABLE
STATUS
Consumable items consumption
status display
5
Consumable item
accumulative
counter display
PRINTER STATUS Consumable items accumulative
consumption status display
6
Factory/Shipping
mode selection
FACTORY MODE
SET
Switching between the Factory mode
and the Shipping mode
7
FUSE status
check
Respective FUSEs status display
8
Engine parameter
setting
SENSOR SETTING Valid/Invalid setups of error detection
by various sensors
9
LED Head serial
number display
LED HEAD DATA LED Head serial number display
10
NVRAM
parameter setting
NVRAM
PARAMETER
Do not use this item
3.4.2.1 Entering self-diagnostic mode (level 1)
1. Make sure that the LCD is in standby state (no Error window is shown) and
press the [Setting] to move to the setting window and then press the following
button in the indicated sequence.
[#]
[0]
[1]
[0]
[3]
[
]
2. Type in the password to enter Service Maintenance Menu. It is [000000] by
default. (Enter 0 six times)
3. Select [Printer Maintenance]
[Engine Diag Mode] in the Service Maintenance
Menu and press the [6].
3.4.2.2 Exiting self-diagnostic mode
1. When the [4] is pressed from Diag Mode (Window displaying/Factory state), the
setting window will return.
