2. TROUBLESHOOTING PROCEDURES
Paper Jams
This section explains how to clear paper jams.
Reference! • For details on the location of each component of the machine, refer to
"Swich scan test" on P. 3-16 and "Motor clutch test" on P.3-18.
Checking Error Messages
When a paper jam occurs, the [Paper jam] or [Document jam] message appears on the
display screen and the <STATUS> key on the operator panel blinks. The error code and
description differ according to where the paper jam occurs.
Clearing Paper Jams
Possible to get burned.
Since the fuser unit right is extremely hot, perform the operation with
care.
Note! • The image drum (the green tube) is very delicate. Handle it carefully.
• Do not expose the image drum to direct sunlight or very bright interior light
(approximately more than 1500 lux). Even under the normal interior light, do
not leave it for more than 5 minutes.
