3. MAINTENANCE MENUS
45762101TH Rev.1
3-9
3.2 Service Bit Menu
Additional Fax Setting menu
(When setup ServiceBit=ON, the following items will be displayed at Admin Setup
→
Fax
Setup)
# Item Settings Description ODA OEL
1 Tone For
Echo (For
Transmission)
Enable
Disable
When an Item is Enable:
First DIS is ignored.
Echo Protection Tone is sent
with V.29.
Interval of DIS and DCS is
1000ms
When an Item is Disable:
First DIS is not ignored.
Echo Protection Tone is not
sent with V.29.
Interval of DIS and DCS is
75ms
Disable Disable
2 Tone For Echo
(For Reception)
Enable
Disable
When an Item is Enable :
Interval of CED and DIS is
1000ms
When an Item is Disable :
Interval of CED and DIS is
075ms
Disable Disable
3 Attenuator 0~15 dB Enter Attenuator. Depends on Country
Code
4 MF Attenuator 0~15 d B Enter MF (Tone) Attenuator. Depends on Country
Code
5 Pulse Make
Ratio
33%
39%
40%
Sets the make rate of DP (10
pps) during call.
It only shows, when ServiceBit
= ON and Tone/Pulse setting =
PULSE.
Depends on Country
Code
6 Pulse Dial Type N
10-N
N+1
It only shows, when ServiceBit
= ON and Tone/Pulse setting =
PULSE.
Depends on Country
Code
7 MF ( Tone)
Duration
75, 85, 100
seconds
Enter MF (Tone) Duration.
It only shows, when ServiceBit
= ON and Tone/Pulse setting =
TONE.
Depends on Country
Code
# Item Settings Description ODA OEL
8 Calling Timer 1~255 second
(s)
Sets the call connection wait
time (TO timer).
Depends on Country
Code
